Precision Optical Windows for Lasers
ARD Optics manufactures standard and high-precision optical windows from sapphire and a wide range of optical glass and crystal materials.
High-precision windows are used as laser output couplers, transmissive optics with high laser damage threshold (LDT), protective windows, beam splitters, and substrates for precision optical and electronic applications.
Materials available:
Sapphire, Fused silica (KU-1, UV-grade), KI (IR-grade), BK-7 glass, Si, Ge, ZnS, ZnSe, MgF₂, BaF₂, BBO, Zerodur, Pyrex.
Typical applications:
- Laser output couplers — transmissive optics with high laser damage threshold (LDT), used in CO₂, Nd:YAG, fiber, and diode laser systems
- Protective windows — shielding sensitive optical and electronic components from dust, moisture, and mechanical damage in industrial laser equipment
- Beam splitters — dividing or combining laser beams in interferometers, metrology systems, and laser diagnostics
- Vacuum chamber viewports — hermetic optical access windows for scientific and industrial vacuum systems
- Semiconductor & microelectronics — substrates and protective elements in lithography, inspection, and wafer processing equipment
Precision Optical Windows for Lasers — Specifications
| Standard quality of optics | High-quality optics (precision optic) | |||||
|---|---|---|---|---|---|---|
| Sapphire | Fused silica, Quartz, Germanium, Si |
Glass BK-7, other glass |
Sapphire | Fused silica, Quartz, Si |
Glass BK-7, other glass |
|
| Diameter | 2 – 350 mm | |||||
| Diameter tolerance | +/− 0.02 mm | |||||
| Thickness | 0.3 – 300 mm | |||||
| Thickness tolerance | +/− 0.02 mm | |||||
| Flatness λ | λ/2 – λ/4 | λ/4 | λ/4 | λ/8 λ/10 |
λ/8 λ/10 |
λ/8 λ/10 |
| Surface quality S/D (MIL-13830) | 60/40 | 40/20 | 40/20 | 20/10 10/5 |
10/5 | 10/5 |
| Parallelism | 3 arc min. | 3 arc min. | 3 arc min. | 5 arc sec. | 5 arc sec. | 5 arc sec. |
* Custom specifications available upon request. Contact us for a quote.
